For two uses machine GS-2 for the high-speed automatic control
For two uses machine for the high-speed automatic control
Grand servo GS-2
Grand servo GS-2
Sewing machine control panel
■Characteristic
●I only push the button, and the choice of the mode to sew of 6 patterns is OK.
Operation became very easy.
The flat splinter nonstop rimless tatami is easily done by the choice of the mode to sew, too.
Operation became very easy.
The flat splinter nonstop rimless tatami is easily done by the choice of the mode to sew, too.
Specifications of grand servo GS-2
| |||
Full length
| 3,200mm (6 sun of 10 shakus)
| ||
Height
| 1,450mm (8 sun of 4 shakus)
| ||
Width
| 1,490mm (9 sun of 4 shakus)
| ||
Tatami mat stand height
| 800mm (6 sun of 2 shakus)
| ||
Weight
| 675㎏
| ||
Motor -
Body sewing machine use Body forwarding use It is for body cutting Tatami mat stand use Tatami mat tightening use | Single phase 100V
| Ministry of three 200V
| |
With 200W1/10 slowdown brakes (nothing)
| With 200W1/10 slowdown brakes (nothing)
| ||
400W (nothing)
| 400W (nothing)
| ||
250W (nothing)
| 200W (nothing)
| ||
300W (nothing)
| 200W (nothing)
| ||
200W (nothing)
| 200W (nothing)
| ||
Rating power consumption
| Two 15A (a ministry of three or single phase)
| ||
Sewing method
| Two thread final sewing
| ||
Sewing interval
| Give back flat splinter 15-30mm (no stage); 15-55mm (no stage)
| ||
※I may change this way for a thing at the time of the new sale.
